Upload GPX

Replace route data while keeping your current sticker settings.

Choose a GPX track file. RouteTag reads the route and any waypoint-like entries that can become checkpoints.

GPX file No file selected

Sticker width mm Sticker height mm

Set the physical sticker size. The preview and exports use these dimensions.

Typography

Font family

Controls the font used for sticker text. RouteTag uses bundled font suggestions until you load local device fonts.

Loading device fonts may ask for browser permission. The font list stays local to this browser and adds available fonts to the selector.

Background

Mode Color

Choose a solid sticker background or transparent output for formats that support it.

Elevation

Line color Line opacity Line width mm Fill start color Fill start opacity Fill end color Fill end opacity

Line settings affect the route profile outline. Fill settings control the soft elevation area under the profile.

Axes

Line color Line opacity

Axes frame the elevation profile and distance scale.

Title

Show distance Show elevation

These checkpoints come from the GPX file. Enabled rows are shown on the sticker and exported as POI GPX files.

Add checkpoints by latitude and longitude, or by a kilometer value along the route. Pasting a coordinate pair into Latitude will split it. Checkpoint codes are counted automatically unless you overwrite them.

Name Type Latitude Longitude

Prominent peaks are detected automatically from the elevation profile. They are visual labels only and are disabled by default.

Labels

Distance label Gap mm Name size Distance size

Controls checkpoint label spacing and text sizes next to the profile. Codes are auto-counted as CP01, CP02, and so on until a code is manually overwritten. Emoji can be used, but final rendering depends on the selected font and target device.

Connector

Line color Line opacity

Connector lines link checkpoint labels to their position on the elevation profile.

Text

Color Opacity

Text styling affects checkpoint codes and distance labels, including emoji when the selected font supports them.

Halo

Color Opacity

Halo styling improves checkpoint dot contrast against the profile background.

Peaks

Peak labels are drawn inside the elevation graph with a background for readability. Detected peaks are disabled until you enable them.

Detection

Minimum climb Peak spacingkm

Minimum climb is the required rise from the lower nearby valleys to count as a peak. Peak spacing is the route-kilometer window used to score peaks and the minimum distance kept between automatic peaks.

Peak label

Content Size Text color Text opacity

Choose whether peak labels show elevation, custom text, or both, then set their text size and color.

Marker

Line color Line opacity

Marker styling controls the dot and connector line from the peak position to its label.

Peak background

Background Background opacity

Background styling adds a readable box behind peak text inside the elevation graph.

Arrange print sheet

Exports one GPX waypoint file for every enabled checkpoint. See device notes below.

Waiting for GPX

Using POI GPX files on bike computers

RouteTag exports each enabled checkpoint as a GPX waypoint file. Many GPS devices treat these as saved locations, favorites, or POIs that can appear on the map.

Garmin Edge devices commonly import GPX files by copying them to Garmin/NewFiles over USB, then safely disconnecting the device so it can process the files.

Wahoo ELEMNT devices usually import GPX route files through the Wahoo app and sync them to the computer. Standalone waypoint or POI GPX behavior can differ from Garmin workflows.

Hammerhead/Karoo can show POIs from supported synced route services, but POIs from GPX imports may not appear. Check your device manual or vendor app workflow before relying on exported POIs during a ride.
